Conventional Pipe Turning Roll With Anti Drift Function For Tube Seam Welding

Product Details

Place of Origin: China

Brand Name: Ronniewell

Certification: CE,ISO,CSA

Model Number: HGK20

Payment & Shipping Terms

Minimum Order Quantity: 1set (including 1 power unit & one idler unit)

Price: pls confirm with us

Packaging Details: Mainframe naked, spare parts packed in case

Delivery Time: 30working days

Payment Terms: 30% TT in advance, 70% TT before the shipment

Supply Ability: 40set/month

Get Best Price
Highlight:

pipe rotators for welding

,

tank turning rolls

Type:
Roller Center Distance Bolt Adjustable
Structure:
With Manual Trolley
Feature:
Anti Drift Function
Application:
Pipe Seam Welding
Rated Load:
20000kg
Pipe Dia Range:
500~3500mm
Roller Material:
Forged Steel Roller With PU Coated
Speed Contorl:
Inverter Control
Type:
Roller Center Distance Bolt Adjustable
Structure:
With Manual Trolley
Feature:
Anti Drift Function
Application:
Pipe Seam Welding
Rated Load:
20000kg
Pipe Dia Range:
500~3500mm
Roller Material:
Forged Steel Roller With PU Coated
Speed Contorl:
Inverter Control
Conventional Pipe Turning Roll With Anti Drift Function For Tube Seam Welding

Conventional Pipe Turning Roll With Anti Drift Function For Tube Seam Welding



Conventional Pipe Turning Roll With Anti Drift Function For Tube Seam Welding 0

Conventional Pipe Turning Roll With Anti Drift Function For Tube Seam Welding 1





Brief introduction:



The pipe turning roll is used in 1+1 pipe growing line,working together with fit up rotator.

Anti drift structure is simple but high effictive with low cost, compare with sensor anti drift type.







Detail description:

  1. Various models ranging from 5 tons to 500 ton capacity.

  2. Higher models are custom built upon request.

  3. Our set of pipe turning roll consists of 2 parts: a motorized drive (power) unit & an idler supporting unit.

  4. The power unit is driven by a heavy duty AC motor.

  5. It is designed according to internationally proven specifications to ensure constant speed with outer balance load of 15%.

  6. The heavy duty tyres are designed to 90 durable hardness with high stress PU cushion mounts to absorb shock loads and prevent gear box damage.

  7. The DC electronic function or inverter comes with a remote control panel / operator pendant with interlocking reversing systems operating at temperatures in excess of 60%.

  8. Idler unit with anti drift fixture. The structure is simple but very effective.






Functions:



  1. Forward/stop/reverse

  2. Rotation speed

  3. Driving vehicle forward/stop/reverse

  4. Emergency-stop

  5. Anti drift function.






More models technical parameters of the pipe turning roll:

Model

HGK-5

HGK-10

HGK-20

HGK-40

HGK-80

Max.Load capacity(ton)

5

10

20

40

80

Vessel dia. Range (mm)

250~2300

320~2800

500~3500

600~4200

800~5000

Dia.& width of roller (mm)

250X120

300x140

350x160

400x180

450x2x200

Adjustable mode

Bolt adjustable

Motor power (kW)

2x0.37

2x0.55

2x1.1

2x1.5

2x3

Roller speed (m/min)

0.1~1 Variable Frequency Drive








Applied industry:

  1. Wind power fabrication

  2. Pipe manufacturing industries

  3. Pressure vessels

  4. Chemical & fuel storage tank fabrication

  5. Any heavy cylindrical job







Feature:

  1. The pipe turning roll HGK series have a strong and durable construction with creates a very high stability.

  2. The steel wheels of the HGK which enclose locked solid PU tyres. From the capacity of 150 tons are they equipped with fully steel wheels.

  3. These turning rolls have top-class electronic components, stepless adjustable speed of the driven part in CE marked.

  4. The favourable price performance ratio yields will ensure a quick payback of your investment.

  5. HGK pipe turning roll can be supplied with a capacity from 5000 kg up to 1200 Tons.

  6. We also provide tailor-made HGK welding rotators according to your special requirements.




Exhibition picture:
Conventional Pipe Turning Roll With Anti Drift Function For Tube Seam Welding 2






Points you may concern:
Customization - Can your machine or other products be customized?
Ronniewell: Sure. As a professional manufacturer, we have our own engineer team, who is good at design, develop & build special solution catering for your individual requirement.


Transportation-What about the transportation?
Ronniewell: Seaway is the most common transportation way for oversea trading. Depends on your location, combined transport by rail and sea is also an option. Certainly railway transportation is also acceptable if it is the most suitable approach.


After sale service - What about the after-sale service?
Ronniewell: We provide 12month guaranty period for the whole machine quality. During this time, any issue proved because of the machine flaw itself,we would take the whole responsibility of it. Except of the guaranty period,technical advisory support is available freely covering the whole using life of the machine. Engineer service on user premises is also available for necessary.
