Heavy Tubular Section Outer Circle Seam 6m Gantry Welding Platform Transverse Trolley
- Gantry welding platform is using to manipulate the welding kits, position the weld torch to required position for welding in a stable and secure manner.
- Each of walking beams is driven by a motor reducer, forming a double-drive system, which makes the operation smooth and reliable.
- Mainly used by SAW welding method for high efficiency high quality welding.
- Flux recovery system is optional as per choice. Welding seam tracing, monitoring & other accessories available as per choice.
- The electric control system consists of one electric control box and pendant controller
- Widly used as offshore monopile production equipment, others purpose like tube tower, jackt and so on job fabrication.
- Heavy duty offshore foundation/monopile/wind tower/bullet tank/pressure vessel section fabrication using gantry welding platform
- Liftable working platform suitable for diameter range upto 6m sections outer circumferential seam SAW welding;
- Single welding station using for heavy duty section outer circumferential seam countinuous welding.
- Liftable working platform suitable for various diameter section.
- Various kinds of welding methods such as single wire / tandem twin SAW/TIG/MIG applicable on the gantry welding platform.
- Compare with welding column and boom, gantry welding platform with sufficient working space for welder operation. Increase the comfort of welder, decrease working intense & improve the working efficiency.
- Complete & considerate safety measure, including safety fence, anti-fall device, anti turn-over device & whole electric safety measure.
Technical parameters :
|Platform height range from the ground
|Lift speed: mm/min
|Platform length * width
||Main components tempering treatment eliminating inner stress
|Cable winding device
||auto cable winding device
||offshore foundation/monopile/wind tower/bullet tank/pressure vessel
What Ronniewell can do for Ronniewell customers:
- Give you high quality products.
- Give you five-star price.
- Give you suitable recommendation.
- Give you good after-service.
- Give you professional technical guide.
- Warmly welcome you visit our factory.
Points you may concern:
Customization - Can your machine or other products be customized?
Ronniewell: Sure. As a professional manufacturer, we have our own engineer team, who is good at design, develop & build special solution catering for your individual requirement.
Transportation-What about the transportation?
Ronniewell: Seaway is the most common transportation way for oversea trading. Depends on your location, combined transport by rail and sea is also an option. Certainly railway transportation is also acceptable if it is the most suitable approach.
After sale service - What about the after-sale service?
Ronniewell: We provide 12month guaranty period for the whole machine quality. During this time, any issue proved because of the machine flaw itself,we would take the whole responsibility of it. Except of the guaranty period,technical advisory support is available freely covering the whole using life of the machine. Engineer service on user premises is also available for necessary.
